Processor Intel Core i3-1005G1
Graphics Integrated Intel UHD Graphics
Chipset Intel SoC Platform
Memory Slots One memory soldered to systemboard, one DDR4 SO-DIMM slot, dual-channel capable
Max Memory Up to 12GB (4GB soldered + 8GB SO-DIMM) DDR4-2666 offering
Storage 256GB SSD M.2 2242 PCIe 3.0x2 NVMe
Storage Support "Model with 35Wh battery: up to two drives, 1x 2.5"" HDD + 1x M.2 SSD
• 2.5"" HDD up to 1TB
• M.2 2242 SSD up to 512GB
• M.2 2280 SSD up to 1TB
• Optional Intel Optane Memory integrated with SSD, M.2"
Card Reader 4-in-1 Card Reader
Optical None
Audio Chip High Definition (HD) Audio
Speakers Stereo speakers, 1.5W x2, Dolby Audio
Camera 0.3MP with Privacy Shutter
Microphone 2x, Array
Battery Integrated 35Wh
Max Battery Life MobileMark 2014: 7.3 hr (35Wh + integrated graphics)
Power Adapter 65W Round Tip (2-pin, Wall-mount)
DESIGN
Display 15.6" FHD (1920x1080) TN 220nits Anti-glare
Touchscreen None
Keyboard Non-backlit
Surface Treatment IMR (In-Mold Decoration by Roller)
Case Material PC + ABS (Top), PC + ABS (Bottom)
Dimensions (WxDxH) 362.2 x 253.4 x 19.9 mm (14.26 x 9.98 x 0.78 inches)
Weight 1.85 kg (4.08 lbs)
SOFTWARE
Operating System None
CONNECTIVITY
Ethernet None
WLAN + Bluetooth 11ac, 2x2 + BT5.0
Standard Ports "1x Power connector
1x Card reader
1x HDMI 1.4b
1x Headphone / microphone combo jack (3.5mm)
1x USB 2.0
2x USB 3.2 Gen 1"
